Swosh Interactive Touchscreen Premium Series 86 inch
The Swosh Interactive Touchscreen Premium Series 86 Inch offers 4K UHD resolution, zero bonding technology, and multi-touch support. It runs on Android 13 with a powerful RK 3588 CPU, providing smooth performance. Ideal for interactive presentations, meetings, and collaborative workspaces, this display features a smart control pad, various connectivity options, and a sleek design.
Description
Swosh Interactive Touchscreen Premium Series 86
The Swosh Interactive Touchscreen Premium Series 86 Inch offers 4K UHD resolution, zero bonding technology, and multi-touch support. It runs on Android 13 with a powerful RK 3588 CPU, providing smooth performance. Ideal for interactive presentations, meetings, and collaborative workspaces, this display features a smart control pad, various connectivity options, and a sleek design.
Photo/Screen Record Video
Capture high-quality photos and screen recordings effortlessly.
Split Screen
Boost productivity by working on multiple tasks simultaneously with split screen functionality.
Whiteboard
File Import/Export
Seamlessly integrate documents.
Pen Colour/Shape
Customize annotations with various pen colors and shapes.
INTELLIGENT FOCUS
Intelligent focus technology enables individual close-ups for multiple participants simultaneously, delivering an immersive in-person experience.
Supports Various Interface
The Swosh Interactive Touchscreen offers diverse interfaces including USB, HDMI,Touch USB, Type-C, Power Button, Light Sensor, IR Remote Receiver
Built-in 8 Microphone Array
Experience crystal-clear audio with an advanced 8 microphone array.
Components
AI Camera
Wi-fi 6
8 Microphones Array
Quad Core CPU (A75/A55)
Best in class Features
Anti Glare Matt Screen
Support Palm Annotation
Antibacterial Touchscreen
Up to 50-point Touch
Wireless Screen Sharing
Design for Ease of Collaboration
Multi-Tasking and Multi-Windows
Cloud drive
Pen pick-up detection for prompt pop-up and access
Supported Softwares
Product Specification
| Model | SW86TSG3P |
| Screen Size | 86" |
| Bonding Technology | Zero Bonding |
| Aspect Ratio | 16:9 |
| Max Visual Area (HIV) (mm) | 1895.04 x 1065.96 |
| Resolution (HIV) | 4K UHD 3840 x 2160 |
| Brightness(cd/m2) | >= 350 |
| Contrast Ratio(Typ) | 1100:1/1200:1/1300:1/4000:1/5000:1/6000:1 (subject to change by using different open cells) |
| Viewing Angles (HIV) | 178 degress |
| Refresh Rate | 60Hz |
| Response Tirne | 8ms |
| Back Light | DLED |
| Life | >= 50000 hours |
Touch
| Touch Type Supported Systems | Windows10/Windows8/Windows7/ Windows XP/Android/Linux/Mac OS X/Chrome |
| Android writing point | 20 points touch |
| OPS writing point | 50 points touch |
| Minimum identifier | 1.5mm (over 90% of the area) |
| Response time | <= 2.0ms |
| Touch Accuracy | ±0.5mm (over 90% of the area) |
| Writing Height | <= 2mm |
| Writing Display | Single stylus pen with two color |
| Output Coordinates | 32767 (W) x 32767 (D) |
Android OS
| System Version | Android 13.0 |
| Solution | RK 3588 |
| CPU/GPU | A76*4 +A55*4, 2.4GHZ Arm Mali-G610 Mc4 |
| RAM/ROM | 166B DDR4+256GB eMMC |
| Bluetooth | Version 5, 2.4GHz, 0~10m working Distance |
| Wi-Fi | Version 802.11ac/b/g/n/ax, 2.4GHz/5GHz, 0~10m Working |
Connectivity
| Front Interfaces | USB 3.0 x 2, HDMI IN x 1, Touch USB x 1, USB Type-C x 1 (full-featured), Power Button/ Light Sensor/ lR Remote Receiver |
| Rear Interfaces | TYPE-C IN, TOUCH OUT 3.0 x 2, HDMI IN x 3, HDMI OUT, DP IN, TYPE-C OUT, USB IN 3.0 x 2 |
| Bottom Interface | LINE OUT, RJ45 OUT, RJ45 IN, AUDIO IN, VGA IN, USB IN, OPTICAL RS232. TOUCH OUT 3.0 |
General
| Camera & Mic (optional) | Al 48M Pixel Camera/8 Array Microphones |
| Speaker | Soundtrack: 2.2 2 x 16W + 2 x subwoofer |
| Vocalisation | Integrated speakers |
| Cast Screen | 9 |
| Screen Size | 86" |
| Max. Power Consumption | 450W |
| Product Dimensions (mm) | 1952 x 1180.4 x 115 |
| Packing Dimensions (mm) | 2120 x 220 x 1325 |
| Net Weight (kgs) | 66±1 |
| Gross Weight (kgs) | 76.2±1 |
| Accessories | Power Cable x 1, Stylus Pen x 2, Remote Control x 1 |
